SPECIFICATIONS:
Dimensions (Mount Included)
189 x 189 x 125 mm
(7.44 x 7.44 x 4.92")
Weight (Mount Included)
530 g
(1.17 lb)
Gain
19 dBi
Networking Interface
(2) 10/100/1000 Ethernet Port, Wi-Fi for Management
Enclosure
Outdoor UV Stabilized Plastic
Max. Power Consumption
8W
Power Supply
24V, 0.5A Gigabit PoE Adapter (Included)
Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)
Wind Loading
45.4 N @ 200 km/h
(10.2 lbf @ 125 mph)
Wind Survivability
200 km/h
(125 mph)
Certifications
CE, FCC, IC
Mounting
Pole-Mount (Kit Included)
Wall-Mount (Not Included)
ESD/EMP Protection
± 24kV Contact/Air
Operating Temperature
-40 to 80° C (-40 to 176 F)
Operating Humidity
5 to 95% Noncondensing
Salt Fog Test
IEC 68-2-11 (ASTM B117),
Equivalent: MIL-STD-810 G Method 509.5
Vibration Test
IEC 68-2-6
Temperature Shock Test
IEC 68-2-14
UV Test
IEC 68-2-5 at 40° C (104° F),
Equivalent: ETS 300 019-1-4
Wind-Driven Rain Test
ETS 300 019-1-4,
Equivalent: MIL-STD-810 G Method 506.5
