HARDWARE FEATURES |
Interface | Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *) |
Button | Reset |
Power supply | 802.3af/A PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included) |
Power consumption | EU: 10.5 W
US: 12.6W |
Dimensions | 8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm) |
Antenna type | 3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi |
Mounting | Ceiling /Wall Mounting (Kits included) |
Physical security lock | Yes |
Hardware watch dog | Yes |
Interface | Gigabit Ethernet (RJ-45) Port *1 (Support IEEE802.3af PoE and Passive PoE *) |
Button | Reset |
Power supply | 802.3af/A PoE
24V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included) |
Power consumption | EU: 10.5 W
US: 12.6W |
Dimensions | 8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm) |
Antenna type | 3 Internal Omni *
2.4GHz: 4dBi
5GHz: 5dBi |
Mounting | Ceiling /Wall Mounting (Kits included) |
Physical security lock | Yes |
Hardware watch dog | Yes |
WIRELESS FEATURES |
Wireless standards | IEEE 802.11ac/n/g/b/a |
Frequency | 2.4GHz and 5GHz |
Signal rate | 5GHz:Up to 867Mbps
2.4GHz:Up to 450Mbps * |
Wireless functions | Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
Band Steering
Load Balance
MU-MIMO *
Airtime Fairness *
Beamforming *
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client |
Wireless security | Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support |
Transmission power | CE:
≤20dBm(2.4GHz,EIRP)
≤23dBm(5GHz,EIRP)
FCC:
≤24dBm(2.4GHz)
≤22dBm(5GHz) |
MANAGEMENT |
Omada cloud access | Yes |
Omada app | Yes |
Omada cloud controller | Yes |
Omada controller software | Yes |
EAP controller software | Yes |
Email alerts | Yes |
LED on/off control | Yes |
Management mac access control | Yes |
SNMP | v1,v2c |
System logging local/remote syslog | Local/Remote Syslog |
TELNET | Yes |
SSH | Yes |
Web-based management | HTTP/HTTPS |
L3 management | Yes |
Multi-site management | Yes |
Management VLAN | Yes |
OTHERS |
Certification | CE, FCC, RoHS |
Package contents | AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide |
System requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
Environment | Operating Temperature: 0℃~60℃(32℉~144℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
Certification | CE, FCC, RoHS |
Package contents | AC1350 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP225
Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide |
System requirements | Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10 |
Environment | Operating Temperature: 0 ℃~60 ℃ (32 ℉~144 ℉)
Storage Temperature: -40 ℃~70 ℃ (-40 ℉~158 ℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing |
