SPECIFICATIONS:
HARDWARE FEATURES
Interface
Gigabit Ethernet (RJ-45) Port *2 (Support IEEE802.3af PoE and Passive PoE )
Button
Reset
Power supply
802.3af/A PoE
48V Passive PoE (+4,5pins; -7,8pins. PoE Adapter Included)
Power consumption
12.3 W
Dimensions ( w x d x h )
8.1 × 7.1 × 1.5 in. (205.5 × 181.5 × 37.1 mm)
Antenna type
Internal Omni
2.4GHz: 3* 3.5dBi
5GHz: 3*4dBi
Mounting
Ceiling /Wall Mounting (Kits included)
Physical security lock
Yes
WIRELESS FEATURES
Wireless standards
IEEE 802.11ac/n/g/b/a
Frequency
2.4GHz and 5GHz
Signal rate
5GHz:Up to 1300Mbps
2.4GHz:Up to 450Mbps
Wireless functions
Multiple SSIDs (Up to 16 SSIDs, 8 for each band)
Enable/Disable Wireless Radio
Automatic Channel Assignment
Transmit Power Control (Adjust Transmit Power on dBm)
QoS(WMM)
MU-MIMO
Seamless Roaming
Band Steering
Load Balance
Airtime Fairness
Beamforming
Rate Limit
Reboot Schedule
Wireless Schedule
Wireless Statistics based on SSID/AP/Client
Wireless security
Captive Portal Authentication
Access Control
Wireless Mac Address Filtering
Wireless Isolation Between Clients
SSID to VLAN Mapping
Rogue AP Detection
802.1X Support
64/128/152-bit WEP / WPA / WPA2-Enterprise,
WPA-PSK / WPA2-PSK
Transmission power
CE：
≤20dBm(2.4GHz)
≤23dBm(5GHz)
FCC:
≤24dBm(2.4GHz)
≤24dBm(5GHz)
MANAGEMENT
OMADA app
Centralized management
Omada Software Controller
OC200
Cloud access
Yes (Through Omada Software Controller or OC200)
Email alerts
LED on/off control
Management MAC access control
SNMP
System Logging Local/Remote SYSLOG
Local/Remote Syslog
SSH
Web-based management
HTTP/HTTPS
L3 management
Multi-site management
Management VLAN
OTHERS
Certification
CE, FCC, RoHS
Package contents
AC1750 Wireless MU-MIMO Gigabit Ceiling Mount Access Point EAP245
Gigabit Passive PoE Adapter
Power Cord
Mounting Kits
Installation Guide
System requirements
Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Linux
Environment
Operating Temperature: 0℃~40℃ (32℉~104℉)
Storage Temperature: -40℃~70℃ (-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
