SPECIFICATIONS:
Standards and Protocols
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3af,
IEEE 802.3x, IEEE 802.1q, IEEE 802.1p
Interface
8 10/100/1000Mbps RJ45 Ports
AUTO Negotiation/AUTO MDI/MDIX
Network Media10BASE-T
UTP category 3, 4, 5 cable (maximum 100m)
EIA/TIA-568 100 STP (maximum 100m)
100BASE-TX: UTP category 5, 5e cable (maximum 100m)
1000BASE-T: UTP category 5, 5e, 6 or above cable (maximum 100m)
Fan Quantity
Fanless
Power Supply
External Power Adapter 100VAC ~ 240VAC (Output: 48VDC / 1.25A)
PoE Ports (RJ45)
Standard: 802.3 af compliant
PoE Ports
Port 1- Port 4
PoE Power Budget
55W
Max Power Consumption
5.2W with no PoE device connected
65.2W with 55W PoE devices connected
Max Heat Dissipation
17.6 BTU/h (with no PD connected)
222.4 BTU/h (with 55W PD connected)
Switching Capacity
16Gbps
Packet Forwarding Rate
11.9Mpps
MAC Address Table
4K
Packet Buffer Memory
1.5Mb
Jumbo Frame
15KB
Quality of Service
Support Port-Based/802.1p/DSCP priority
Support 4 priority queues
Rate Limit
Storm Control
L2 Features
IGMP Snooping V1/V2/V3
Link Aggregation
Port Mirroring
Cable Diagnostics
Loop Prevention
VLAN
Supports up to 32 VLANs simultaneously (out of 4K VLAN IDs)
MTU/Port/Tag VLAN
Management
Web-based GUI
Easy Smart Configuration Utility
Transmission Method
Store-And-Forward
Certification
FCC, CE, RoHS
Package Contents
TL-SG108PE
Power Adapter
Installation Guide
Rubber Feet
Operating Temperature
0~40? (32~104)
Storage Temperature
-40~70? (-40~158)
Operating Humidity
10%~90%RH non-condensing
Storage Humidity
5%~95%RH non-condensing
