Aten 2 Port USB3.0 KVMP 4K Display Port Switch

Aten 2 Port USB3.0 KVMP 4K Display Port Switch
  • 49579_thumb_P_1549327487825
  • 49579_thumb_P_1549327508010
  • 49579_thumb_P_1549327509919
  • 49579_thumb_P_1549327509444
or 4x fortnightly payments of $330 with ZipPay
Learn more

Pick Up Time :

Get a $5 credit or a free drink if order not ready on pick up time.

Delivery:

- +
Want to be notified when this item is available for order?

Please enter a valid email address

   Your Store   Question Mark

Your store is set to:

Check live stock level

Bell  Stock Levels May Vary

Make sure to have the correct store selected. Stock levels are different at every store!
We don't do walk-ins, please make sure to order online for Pickup.

Specifications

  • Product Name:
    Aten 2 Port USB3.0 KVMP 4K Display Port Switch
  • Model Number:
    CS1922-AT-U
  • Brand:
  • Warranty Period:
    1 Year

Description



Aten 2 Port USB3.0 KVMP 4K Display Port Switch

The ATEN CS1922 2-Port USB 3.0 4K DisplayPort KVMP™ Switch provides the latest innovations in desktop KVM switching technology for the increasing demand of higher video quality and transfer speeds on modern computers. The ATEN CS1922 offers an unprecedented performance of delivering 4K resolution, the next generation USB 3.1 Gen 1 hub with SuperSpeed 5 Gbps data transfer rates and enhanced user-friendly operations.


As a KVM switch, the CS1922 allows users to access two DisplayPort computers from a single USB keyboard, USB mouse and monitor console. Doing so with ease, the CS1922 provides three convenient switching methods – using front panel pushbuttons, mouse, or hotkeys for flexible access to any computer connected to the installation.


The unique independent switching feature allows the KVM control to focus on one computer while the USB peripheral focus is on another computer. This eliminates the need to purchase a separate USB hub or stand-alone peripheral sharer – such as a print server, modem splitter, etc.


With its rich feature set, the CS1922 is designed to surpass all requirements in graphic design, animation, and video-editing applications. Such as CAD/CAM (computer aided design/manufacturing). The CS1922 allows you to share the audio from each of the connected computers. HD audio transmitted by DisplayPort would offer you a different experience.


Aten 2 Port USB3.0 KVMP 4K Display Port Switch

Specifications
  • Computer Connections: 2

  • Port Selection: Hotkey, Pushbutton, Mouse

  • Console Ports: 2 x USB Type A Female (Black)

                            1 x DisplayPort Female (Black)

                            2 x 3.5mm Audio Jack Female (Green; 1 x front, 1 x rear)

                            2 x 3.5mm Audio Jack Female (Pink; 1 x front, 1 x rear)

  • KVM (Computer) Ports: 2 x USB3.1 Gen1 Type B Female (Blue)

                                          2 x DisplayPort Female (Black)

                                          2 x 3.5mm Audio Jack Female (Green)

                                          2 x 3.5mm Audio Jack Female (Pink)

  • Power: 1 x DC Jack

  • USB Hub: 2 x USB3.1 Gen1 Type A Female (Blue; 1 x front panel; 1 x rear panel)

  • Switches: 2 x Pushbutton

  • On Line /Selected LEDs: 2 (Orange)

  • USB Link LEDs: 2 (Green)

  • Keyboard / Mouse: USB

  • Video: 4096 x 2160 @ 60Hz

  • Scan Interval: 1-99 Seconds (Default: 5 sec.)

  • Power Consumption: DC5V:1.15W:55BTU

  • Operating Temperature: 0-50°C

  • Storage Temperature: -20-60°C

  • Humidity: 0-80% RH, Non-condensing

  • Housing: Metal, Plastic

  • Weight: 0.73 kg ( 1.61 lb )

  • Dimensions (L x W x H): 21.00 x 8.80 x 5.55
